LA-100 DC
- MANIPULATORS MA-8005
- Probe: GNR39, GNR38, RBY45, RBY23, RBY24, WGT71
FSUP Signal Source Analyzer
- FSUP26: Signal Source Analyzer for Phase Noise and VCO test, 1MHz to 26.5GHz; with integrated Spectrum Analyzer, 20Hz to 26.5GHz
- FSU-B23: Preamplifier 20 dB to FSU26, 3.6 - 26.5 GHz
- FSU-B25Electronic attenuator 0 to 30 dB, Preamplifier 20 dB, 10MHz - 3.6 GHz for FSU, FSQ
- FSUP-B60: Low Phase Noise for cross correlation measurement
- FSUP-B61: Cross correlation frequency extension, with preamplifier FSU-B23
SMA100A Signal Generator
- SMA100A Signal generator base unit. Requires frequency option
- SMA-B106 Option: Frequency range 9kHz to 6GHz with electronic attenuator.
Agilent technologies E5071C 300KHz – 20Ghz
- 4-port, 50 ohm, S-parameter test set
- Improve accuracy, yield and margins with wide dynamic range 130 dB, fast measurement speed 8 ms and excellent temperature stability 0.005 dB/°C
E4990A Impedance Analyzer, 20 Hz to 20 MHz
- ±0.08% (typical ±0.045%) basic impedance measurement accuracy
- 25 mΩ to 40 MΩ wide impedance measurement range (10% measurement accuracy range)
- Measurement parameters: |Z|, |Y|, θ, R, X, G, B, L, C, D, Q, Complex Z, Complex Y, Vac, Iac, Vdc, Idc
- Built-in DC bias range: 0 V to ±40 V, 0 A to ±100 mA
- Enhanced measurement speed option (option 001. For 10M/20M/30M/50M options only)
- 4-channel & 4-trace on 10.4 inch color LCD with touch screen
- Data analysis function: Equivalent circuit analysis, limit line test
Customized 3-D scanner
- Resolution 5µm, controlled through customized Matlab script
- Suitable for Ultrasonic, E-field, H-field scan
Electronics & Innovation 2100L
- Class of Operation: Class A
- Frequency Range: 10 kHz to 12 MHz
- Rated Power Output: 100 W
- Power Gain: 50 dB
- Gain Flatness: ±1.5 dB
- Input Power for Rated Output: 1.0 mW / 0 dBm
- Input Impedance: 50 Ohms
- Output Impedance: 50 Ohms
- Harmonic Level: <-25 dBc
- Size (H x W x D): 5.3" x 16.5" x 18.4" (134.5 mm x 420 mm x 467 mm)
- Weight: 35 lbs (16 kg)
- 100 - 240 Vac; 47-63 Hz
- RTO1044: Digital oscilloscope, 4 channels, 4GHz bandwidth, sampling rate 10GSa/s per channel, sampling memory 20MSa per channel / max. 80MSa(1 channel), four 500MHz passive voltage probes, BNC trigger-out
- RTO1024: Digital Oscilloscope 2GHz, 4Channel, with 4 Passive 500MHz Probes and Option: RTO-B1 = Mixel Signal Option, 400MHz, additional 16 digital channels; WIN7 = Windows 7 Operation System
Spec:
- Logic analyzer, portable mainframe, 2modules, certificate of traceable calibration standard
- TLA7AC2 68 Ch. State/Timing Module – TLA7000 Logic Analyzer Module, 68 Channels, 8 GHz MagniVu Timing, 235 MHz State Clock, 2 Mb Record Length
- P6810: Logic Analyzer Probe For Tla7axx,34 Channel, General Purpose, Single Ended/Differential Clock, Single Ended/Differential Data
- PG3ACABA1: the moving pixel company; digital pattern generator module in an external cabinet with power supply; universal euro power cord
- SR780 Dynamic Signal Analyzer
- DC to 102.4 kHz bandwidth
- 90 dB dynamic range
- ow-distortion synthesized source
- 145 dB dynamic range (swept-sine)
- Real-time octave analysis
- Up to 32 Mbyte memory
- GPIB and RS-232 interfaces
Voltera V-One Desktop PCB Printer
The Voltera V-One creates two layer prototype circuit boards on your desk. Gerber files go in, printed circuit boards come out.
Link to datasheet:
Spec: Signal and Spectrum Analyzer 10Hz to 30GHz, -154dBm to 30dBm, resolution bandwidth 1Hz to 10MHz
- RF preamplifier 9kHz to 30GHz (FSV-B24)
- Link to datasheet:
Agilent Technologies 81160A
- Generation of 330-MHz pulses and 500-MHz function/arbitrary waveforms with a 2.5-GSa/s sample rate and 14-bit vertical resolution;
- Selectable crest factors for white Gaussian noise lets engineers determine how much distortion to apply to a device during stress testing to meet various serial bus standards;
- Glitch-free timing parameter changes allow engineers to change the frequency without drop-outs or glitches and enable continuous operation without rebooting or resetting the device under test; and
- Arbitrary bit patterns show capacitive load of the channels using simple pattern settings. Complex measurement setups are no longer necessary to test designs to their limits.
- Pulses 330 MHz, 500 MHz sine waves, 660 Mbit pattern
Pro 800
- PRO800 - 2-Slot Benchtop Enclosure,
- TED8040: The TED8000 Modules are Temperature Controllers that are capable to control TEC elements (Peltiers) in order to maintain a constant temperature of e.g. laser diodes
Keithley 2045 (2 units)
- Five instruments in one (IV Source, IVR Measure)
- Seven models: 20-100W DC, 1000W pulsed, 1100V to 1μV, 10A to 10pA
- Source and sink (4-quadrant) operation
- 0.012% basic measure accuracy with 6½-digit resolution
- 2-, 4-, and 6-wire remote V-source and measure sensing
- 1700 readings/second at 4½ digits via GPIB
- Pass/fail comparator for fast sorting/binning
- Available high-speed sense lead contact check function
- Programmable DIO port for automation/handler/prober control (except Model 2401)
- Standard SCPI GPIB, RS-232 and Keithley Trigger Link interfaces
- Measurement range: DC to 100 kHz
- Resolution: 1 μV, 100 nA, 1 mΩ, 1 pF, 1 Hz, 0.1 °C/F
- Basic accuracy: 0.015 % (DC)
- 5¾-digit display (480 000 counts
- Histogram, bar and trend charts on 4.3-inch color graphical display ease monitoring and speed up statistical analysis
- Measure with confidence, with 35 ppm basic DCV accuracy
- Test low power devices with low DC current measurement range from 100 µA to 10 A
Datasheet:
Mantis Elite
2x to 20x magnification options
