Lab Facilities

Power Circuits and Systems Research Laboratory

Below is a list of our major characterisation instruments.

Opal-RT OP5600:

The OP5600 is a complete simulation system. It contains a powerful target computer, a reconfigurable FPGA and signal conditioning for up to 256 I/Os.

Microgrid HIL Real-Time Simulation │ Microgrid Hardware-in-the-Loop



dSPACE SCALEXIO:

The modular dSPACE SCALEXIO system can be used for hardware-in-the-loop (HIL) and rapid control prototyping (RCP) applications. It is highly scalable, provides high-performance processor technology for demanding real-time requirements as well as comprehensive, precise, and fast I/O capabilities.

SCALEXIO - P.G. Intergroup

Typhoon HIL404:

Typhoon HIL is the technology leader in controller hardware in the loop (C-HIL) solutions for e-mobility, e-drives, renewables, microgrids, and other applications.

HIL404 - 上海汉象智能科技有限公司

SpeedGoat Performance Real-time Target Machine:

Speedgoat real-time target machines and Simulink Real-Time™ are expressly designed to work together to create real-time systems for desktop, lab, and field environments.

Performance real-time target machine | Speedgoat

dSPACE MicroLabBox:

MicroLabBox is an all-in-one development system for the laboratory that combines compact size and low system costs with high performance and versatility.

MicroLabBox - dSPACE



PELab | The Power Electronics Rapid Development System:

The PELab is a modular power electronics development system that connects to multiple controllers and real-time HIL simulator simultaneously. The PELab can operate in multiple modes that make the research and development cycle faster. The PELab can be worked with various commonly used power electronics topologies, while the banana connectors on the back panel enable different application circuit configurations.

PELab Power Electronics Rapid Development System

PELab Rear Panel

Three-phase inverter SEMITEACH:

This SEMITEACH SEMIKRON three-phase pedagogical inverter features a three-phase IGBT transistor inverter, a three-phase rectifier and an energy recovery chopper.

ERM Automatismes Industriels
